| Specification | ||
| Image Device: | 1/4 inch SHARP CCD | |
| TV System: | PAL:25f/s NTSC: 30f/s | |
| effective Pixels: | PAL(512*582 Pixels) / NTSC(512*492 pixels) | |
| Sensing Area: | 4.9MM*3.7MM | |
| Scanning System: | 2:1 InterLace | |
| Sync. System: | Internal | |
| Resolution: | 420TV lines | |
| Minimum Illumination: | 0.1 Lux (day), 0 Lux ( with IR) | |
| IR light | automatically on in the day mode | |
| Video Output: | 1.0vp-p, 75Ohm | |
| Consumption: | 0.45W | |
| AGC: | Auto | |
| S/N Ration: | Better than 48dB | |
| Micro | Option, help the drive to head the vehicle rear voice | |
| Whitle Balabce: | Auto | |
| Electronic Shutter: | 1/60(NTSC) 1/50(PAL)~1/100,000 Second | |
| Backlight Cpmpensation: | Auto | |
| Current consumption: | Max. 150mA | |
| Power Supply: | DC 12V (Fault ) , Wide Range :9-35V (Option) | |
| Lens Angel: | 120° | |
| Connector: | Air head or RCA (Option) | |
| Extention Cable: | 6 meters (Default ) , 10 or 15 meters (Option） | |
| Operating Temperature: | -20℃ ~+70℃, RH 95% MAX | |
| Strorage Temperature: | -30℃~+80℃ RH95% MAX | |
| What is the package : | Camera unit / entention cable / Video out connector ( Video out default with male connector ) / Power cable / Screws X 4 PCS / Rubber base | |
